Drive a recycling-oriented society by converting organic waste into concentrated bio-liquid fertilizer !
Break away from dependence on foreign countries for fertilizer raw materials. Stop the rising price of fertilizers.
Reduce CO₂ increase and global warming.
Dependence on foreign countries for fertilizer raw materials
soaring fertilizer prices
Increase in CO₂, global warming
有機性廃棄物をエネルギー+濃縮バイオ液肥にして、真・循環型社会を実現する!
肥料原料の海外依存から脱却
肥料価格の高騰を止める
C O ₂ の増加、地球温暖化を抑える
Mission
●ミッション
日本は、窒素、リン、カリウムの化学肥料原料のほとんどを海外に依存しています。しかも窒素肥料製造においては大量 の化石燃料を使用するため、地球温暖化防止の観点からも問題です。さらに、化学肥料・化学合成農薬を多用した現代農業は生物多様性を喪失させ、生態系サービスの機能も著しく減少させています。
他方、2012年には固定価格買取制度が導入されましたが、有機性廃棄物によるメタン発酵ガス発電は、発酵残渣である 消化液の有効利用が隘路となって、その進捗は遅々たるものです。それは消化液が95%以上が水分であり、貯留・散布 コストが高く、成分調整もできず、懸濁物質も含まれているために、消化液は我が国の農業利用に向かないからです。それに浄化処理を選択すれば処理費用が高額になるからです。
わたしたちは、この課題を解決するために、研究を重ね、特許取得した特殊バイオ技術の開発に成功しました。それが、 Bio-CLF(バイオクリフ) です。
この技術の圧倒的な有効性をご理解いただき、「真・循環型社会」実現のための活用を、みなさまといっしょに進めていこうと考えています。

化学肥料原料の輸⼊相⼿国、輸⼊量
主な化学肥料の原料である尿素、りん安(りん酸アンモニウム)、塩化加⾥(塩化カリウム)は、ほぼ全量を輸⼊。
世界的に資源が偏在しているため、輸⼊相⼿国も偏在。
尿素はマレーシア及び中国、りん安は中国、塩化加⾥はカナダが主な輸⼊相⼿国。
※ 資料:財務省「貿易統計」等を基に作成(令和2年7⽉〜3年6⽉)

Japan depends on foreign countries for most of its raw materials for chemical fertilizers such as nitrogen, phosphorus and potassium. Moreover, since the production of nitrogen fertilizer uses a large amount of fossil fuel, it is also a problem from the viewpoint of preventing global warming. Furthermore, modern agriculture, which makes extensive use of chemical fertilizers and chemically synthesized pesticides, is causing a loss of biodiversity and significantly reducing the functions of ecosystem services. On the other hand, although a feed-in tariff system was introduced in 2012, progress in methane fermentation gas power generation using organic waste has been slow due to the bottleneck in the effective use of digestive juice, which is the fermentation residue. is. This is because digestive juice is more than 95% water, is expensive to store and spread, cannot be adjusted in composition, and contains suspended solids, making it unsuitable for agricultural use in Japan. On the other hand, if you choose purification treatment, the treatment cost will be high. In order to solve this problem, we have conducted extensive research and succeeded in developing a special biotechnology that we have acquired a patent for. That is Bio-CLF. We hope that you will understand the overwhelming effectiveness of this technology, and we will work with you to promote its utilization.
What is Bio-CLF ?
●Bio-CLF Labとは
そこで、本研究室では、メタン発酵消化液の利便性を飛躍的に向上させ、広範な需要が期待できるBio-CLF(濃縮バイオ液肥)を開発することより、メタン発酵が容易に導入できる条件を整えました。これにより、有機性廃棄物の処理費用の節減、再生可能エネルギーの供給拡大に加え、消化液の農業利用を契機とした有機農業の進展により、生物多様性の増加にもつながると考えます。
つまり、わたしたちが考える具体的な未来社会は、Bio-CLFによるメタン発酵事業の普及拡大を中心とした脱炭素・NPK 循環社会です。 そして、そのような社会の実現に向けて、消化液からNPKの肥料成分を分離・抽出して、高濃縮Bio-CLFを生産する技術開発を行っています。
この基礎技術については、研究代表者が特許を取得し、関連企業十数社から問い合わせが来ていますが、さらに低コストで濃縮率を向上させようとしています。また、懸濁物質除去に必要な凝集剤については、納豆菌からポリ-γ-グルタミン酸を抽出して天然系凝集剤を開発し、有機資材認証可能なBio-CLFに生産に目処をつけます。
Bio-CLF農産物の生産と販売に向けては、ドローンや精密農業の技術を導入して栽培管理技術の開発と実証試験、販売実験を行い、消費行動分析とその社会経済効果への影響評価も行います。そのため、養豚農家の協力を得て、メタン発酵とBio-CLF製造の装置を設置し、生産されたBio-CLFは、自治体や農協の協力の下、地元農家で使用し、米やイチゴ、トマトなどを生産してイオンで試験販売を行う準備を進めています。

●想定されるBio-CLFの用途
Possible uses
● 植物工場における水耕栽培での利用
● 有機農業や無農薬・無化学肥料栽培での利用
● 耕種農業における土耕栽培での利用
● 施設園芸における養液土耕栽培での利用
● メタン発酵施設での消化液処理への導入
● し尿・汚泥の好気性処理施設への導入
● 畜産経営のふん尿処理施設への導入

一般消化液とBio-CLFの量と質の差
圧倒的に高付加価値な液肥になるので、多様な分野からの期待が高まっています。
●従来技術・競合技術に対するBio-CLFの優位性
Advantages
-
メタン発酵消化液から窒素・リン・カリウムを分離濃縮回収した有機液肥です。
-
消化液の水処理費用よりも安価な製造コストが実現できます。
-
消化液は10倍以上に濃縮でき、貯留・運搬・散布などのコストが大幅削減できます。
-
窒素・リン・カリウムの配合割合を農作物に合わせて自由に変えることができます。
-
養液栽培用にアンモニア態窒素を硝酸態窒素に変換できます。
-
微量肥料成分を含むので、作物の食味も向上します。
-
含有粒子は0.05μm以下のため、潅水装置で目詰まりしません。
-
有機JAS資材の登録認証も可能です。

トマトの養液栽培利用
トマトの実証栽培でも有効性が確認できています。(写真はイメージ)

耕種農業利用
Bio-CLFのブームスプレイヤによる散布実証試験です。
●Bio-CLF実証例《いちご》
Demonstration
いちご「あまおう」で美味しさの試験


有機液肥栽培による新たな美味しさへの挑戦 従来の化学肥料に代えて、Bio-CLFを使用すると、同じ栽培方法でも新しい美味しさをつくることができます。 実証栽培は、現在、米、トマト、いちご、玉ねぎで行っています。穀物や野菜、果物、そして飼料作物など、さまざまな農作物で効果が期待できます。
Therefore, our laboratory has investigated the conditions of dramatically improving the convenience of methane fermentation residuals and developing a concentrated bio-liquid fertilizer (Bio-CLF), which will bring wide-ranging demand for methane fermentation. We believe that this will lead to the reduction of organic waste disposal costs, expansion of the supply of renewable energy, and the development of organic agriculture with the use of digestive fluids in agriculture, which will lead to an increase in biodiversity. The specific future society we envision is a decarbonized, NPK recycling society centered on spreading and expanding the bio-CLF. Bio-CLF will not only reduce the cost of organic waste disposal and expand the supply of renewable energy but will also lead to an increase in biodiversity through the development of organic agriculture, triggered by the use of digested liquid in agriculture. The specific future society we envision is a decarbonized, NPK-circulating society centered on spreading and expanding the methane fermentation business using Bio-CLF. We are developing technology to produce highly concentrated Bio-CLF by separating and extracting the fertilizer components of NPK from the digested liquid. The principal investigator has obtained a patent for this essential technology and has received inquiries from more than a dozen related companies. Still, we are trying to improve the concentration rate at a lower cost. As for the flocculant needed to remove suspended solids, we are developing a natural flocculant by extracting poly-γ-glutamic acid from Bacillus subtilis natto and are on track to produce a Bio-CLF that can be certified as an organic material. For the production and marketing of Bio-CLF agricultural products, we will introduce drone and precision agriculture technologies to develop growing management techniques, conduct demonstration tests and marketing experiments, analyze consumer behavior, and evaluate its impact on socioeconomic effects. For this purpose, we will set up methane fermentation and Bio-CLF production equipment with the cooperation of pig farmers. The Bio-CLF produced will be used by local farmers with the local government and agricultural cooperatives to grow rice, strawberries, tomatoes, etc., which we will sell on a trial basis at AEON.
-
Use in hydroponics in plant factories
-
Use in organic farming and pesticide-free and chemical fertilizer-free cultivation
-
Use in soil cultivation in greenhouse horticulture and cultivated agriculture
-
Use in nutrient solution soil cultivation in institutional horticulture
-
Introduction to digestive fluid treatment at a methane fermentation facility
-
Introduction to aerobic treatment facilities for night soil and sludge
-
Introduction to excrement processing facilities of livestock management
Advantages of Bio-CLF over conventional and competing technologies 1.1. It is an organic liquid fertilizer that separates and concentrates nitrogen, phosphorus, and potassium from methane fermentation digestive fluid. 2. The production cost can be lower than the cost of water treatment of digestive liquid. 3. The digestive juice can be concentrated more than ten times, and the cost of storage, transportation, spraying, etc., can be significantly reduced. 4. Users can freely change the mixing ratio of nitrogen, phosphorus, and potassium according to the crops. 5. We can convert ammonia nitrogen to nitrate nitrogen for hydroponics. 6. Bio-CLF contains micronutrient fertilizer, so the taste of crops is also improved. 7. Because the contained particles are less than 0.05μm, it does not clog the sprinkling system. 8. Registration certification of organic JAS materials is also possible.
The challenge to new taste by organic liquid fertilizer cultivation
Using Bio-CLF instead of conventional chemical fertilizers makes it possible to create new deliciousness even with the same cultivation method. We conduct demonstration cultivation with rice, tomatoes, strawberries, and onions. Bio-CLF is effective in various crops such as grains, vegetables, fruits, and fodder crops.
●各ポジションの役割・メリット
Advantage
市民
・生ごみや下水汚泥などを利活用できます。
・育てた野菜や果物は、美味しく、安全、食べるだけで環境保全に貢献
・新しい美味しさがもうすぐ体験できるかも
・To produce Bio-CLF, we can use organic garbage such as household wastewater and waste. ・Vegetables and fruits grown by Bio-CLF are delicious and safe and contribute to environmental conservation by eating them. ・ You may be able to experience new deliciousness soon.
畜産業、漁業
・メタン発酵プラント&Bio-CLFの導入による飼育頭数拡大
・トータル費用削減
・商品のブランド化 ・地域との共生
・Methane fermentation plant & Bio-CLF increase the number of heads. ・Total cost reduction ・Product branding ・Coexistence with local communities
農業
・商品のブランド化
・Bio-CLFは使いやすい有機肥料
・Bio-CLFは施設園芸で能力を発揮
・さらに植物工場でも利用可能
・Product branding ・Bio-CLF is an easy-to-use organic fertilizer ・Bio-CLF demonstrates its ability in greenhouse horticulture ・Plant factories also can use Bio-CLF.
VC
・地域内ファンドによる資源循環型FIT事業
・企業に求められるカーボンニュートラルの取り組み(GHG削減)
※Bio-CLFによる農産物を使う食品加工企業は、それだけでGHG削減できます。
・Resource-recycling FIT business with local funds ・Carbon neutrality required by companies' Efforts (GHG reduction) *Food processing companies that use agricultural products from Bio-CLF "That alone can reduce GHG."
行政
・一般廃棄物中の生ごみ処理へのメタン発酵プラント&Bio-CLFの導入によるカーボンニュートラル化
・住民への安心安全、持続可能な食料の提供
・有機資源の地域内循環を行政主導で容易に実現
・地域内エネルギー自給率の向上
・Achievement of carbon neutrality by introducing methane fermentation plants and Bio-CLF for processing food waste in general waste ・Provision of safe, secure, and sustainable food to residents ・Easily realize the local circulation of organic resources under government leadership ・Improvement of local energy self-sufficiency
LAB
消費者へ:有機JAS・USDA認証の濃縮バイオ液肥の自社生産と販売事業
畜産へ:畜産糞尿処理のコンサル
市町村・事業者へ:有機性廃棄物処理などのコンサルティング 下水の消化汚泥からもMAP/HAP製造可能
VC:有機性廃棄物によるFIT事業
For consumers: In-house production and sales of organic JAS/USDA-certified Bio-CLF products To livestock farming: Consultation for livestock manure treatment For municipalities and business operators: Consulting on organic waste treatment, etc. Making MAP/HAP possible from digested sewage sludge VC: FIT business using organic waste
その他
・農協と連携した液肥販売
・農協・市町村による散布支援
・水耕栽培
・有機認証の液肥販売
Sales of liquid fertilizer through agricultural cooperatives ●Spraying support by agricultural cooperatives and municipalities ● Hydroponics ●Sales of certified organic liquid fertilizer *Some raw materials cannot be certified as organic.
●矢部 光保教授のメッセージ
Message
あいさつ
本研究室では、農業・農村の持つ新たな可能性を追及する経済学的研究を行っています。つまり、農業・農村は、食料生産に加えて、有機物の循環、再生可能エネルギーの供給、美しい景観や安らぎの場の提供、多様な動植物の保全、伝統的な文化や先人の知恵の継承など、多様な価値を持っています。そこで、より重要な社会的ニーズを見極めながら、健康で安全な生活の上に、循環型社会が構築され、さらには極地や長期間にわたる閉鎖空間での食料生産も想定して、研究と教育を行っています。
例えば、世界の農業環境政策の調査、環境・福祉サービスの経済的評価手法の開発、人々の意識と行動に関する実験経済学的アプローチ、自立分散型エネルギーシステムに基づく循環型社会の形成、農文化システム維持のための制度構築、新たな価値をもつ商品の市場評価、そして途上国における感染症予防や持続可能な農村開発など、農業と環境、健康、バイオエネルギーをキーワードに社会経済的側面から、多様な研究・教育活動を行っています。
特に、近年は、メタン発酵消化液からの肥料成分の分離濃縮回収に向け、天然系凝集剤と化学物質に依存しない凝集技術を開発し、化学肥料に代替可能なBio-CLF(濃縮バイオ液肥)と有機固形肥料の製品化、そして、それら農業利用を重要なテーマとして研究を行っています。
幸いして、濃縮バイオ液肥の小型製造施設は2021年度から稼働し、本格施設も2024年度から稼働予定です。
In this laboratory, we conduct economic research that pursues new possibilities of agriculture and rural areas. In other words, in addition to food production, agriculture and farming villages are not only responsible for the circulation of organic matter, the supply of renewable energy, the provision of beautiful landscapes and places of tranquility, the conservation of diverse flora and fauna, and the inheritance of traditional culture and the wisdom of our predecessors. , have a variety of values. Therefore, while ascertaining more important social needs, we will conduct research and education on the assumption that a recycling-oriented society will be built on a healthy and safe life, as well as food production in polar regions and long-term closed spaces. going.
For example, research on global agricultural and environmental policies, development of economic evaluation methods for environmental and welfare services, experimental economic approaches to human consciousness and behavior, formation of a recycling-oriented society based on independent distributed energy systems, agricultural culture systems From a socio-economic perspective, with the key words of agriculture and the environment, health, and bioenergy, such as system construction for maintenance, market evaluation of products with new value, infectious disease prevention and sustainable rural development in developing countries. research and educational activities. In recent years, in particular, we have developed natural flocculants and flocculation technology that does not rely on chemical substances in order to separate, concentrate, and recover fertilizer components from methane fermentation digestive fluid, and have developed concentrated bio-liquid fertilizer (Bio-CLF) that can replace chemical fertilizers. and commercialization of organic solid fertilizers, and their agricultural use as important themes.
Fortunately, the small-scale manufacturing facility for concentrated bio-liquid fertilizer will start operating from FY2021, and the full-scale facility is scheduled to start operating from FY2024.

Mitsuyasu Yabe
経歴
2009年度 – 現在: 九州大学, 農学研究院, 教授
2007年度 – 2009年度: 九州大学, 大学院・農学研究院, 准教授
2003年度 – 2006年度: 九州大学, 大学院農学研究院, 助教授
2009 – Present: Kyushu University, Faculty of Agriculture, Professor 2007 – 2009: Kyushu University, Graduate School of Agriculture, Associate Professor 2003 – 2006: Kyushu University, Graduate School of Agriculture, Associate Professor
Itoshima
MODEL
福岡県糸島市
大学・民間中心の取り組み
本研究室では、脱炭素・NPK循環システム社会の縮小版として、糸島市の市役所、農家、市民、農協、イオンや産直市場等の協力を得ながら、本システムの実現研究を進めています。具体的には、市内の養豚農家の敷地内に豚ふん尿を利用した小型メタン発酵施設を設置し、その消化液からBio-CLFを製造します。このBio-CLFを地域の水稲農家や施設園芸農家に提供し、生産された農産物はイオンや産直市場で販売します。そして、施設設置農家や栽培農家、消費者、市民からBio-CLFに関する評価を得て、本システムのフィードバックを行い、改善を進めていくというものです。
ここで使用するメタン発酵の原料は、豚ふん尿という産業廃棄物であるため、処理やBio -CLF生産の事業主体は、自治体ではなく民間企業になります。そのため、本研究室も重要な役割を担い、具体的な活動に参画していきます。
この糸島市は人口約10万人で、美しい海岸線と山々に囲まれ、海側エリアは集客力の高い飲食店や雑貨屋が点在しています。また人口161万人の福岡市に隣接しており、大都市と近接している農村というモデルとして一般化しやすい点も特徴です。九州大学からも近いので、きめ細やかな管理や調整が行いやすく、こうした都市での総合的な実証実験で得られる成果や課題、データは社会実装への検証に有効であると考えています。
現在、この糸島市役所や地元農家の協力を得て、水田では水稲や玉ねぎ、施設園芸ではイチゴやトマトの栽培試験を行い、収穫できた農産物を用いて、Bio-CLF農産物の試験販売と市民や農家に対する意識調査を行なっています。

University and private sector-centered initiatives
As a scaled-down version of a decarbonized NPK recycling system society, our laboratory is conducting research on the realization of this system with the cooperation of Itoshima city, farmers, citizens, agricultural cooperatives, AEON, and others. Specifically, we will install a small methane fermentation facility using pig manure on the premises of a pig farmer and produce Bio-CLF from the digested liquid. We will provide this Bio-CLF to local paddy rice and horticulture farmers and sell agricultural products at AEON and markets. Then farmers, consumers, and citizens evaluate this Bio-CLF system and give feedback to us for improving this system.
The raw material for methane fermentation used in this project is swine manure, an industrial waste, so the business entity for treatment and Bio-CLF production is not a municipality but a private company. Therefore, this laboratory will also play an important role and participate in specific activities.
Itoshima City, with approximately 100,000 people, is surrounded by a beautiful coastline and mountains. This city has many restaurants and stores that attract many customers and is adjacent to Fukuoka City, which has a population of 1.61 million. Hence this case is easily generalized as a model of a rural community near a large city. The proximity to Kyushu University makes it easy to conduct detailed management and coordination. The results, issues, and data obtained from a comprehensive demonstration experiment will effectively verify social implementation.
With the cooperation of Itoshima city and local farmers, we are conducting cultivation trials of paddy rice, onions, strawberries, and tomatoes. We sell harvested products to test the market of Bio-CLF and conduct awareness surveys among citizens and farmers.

Maniwa
MODEL
Maniwa City, Okayama Prefecture
岡山県真庭市
自治体中心の取り組み
岡山県真庭市は、北部が中国山地を形成し、人口約41,000人です。この真庭市は、木質系バイオマス利用のモデル地域としてこれまで重要な活動を担ってきました。そして、その真庭市が湿潤系バイオマスでも新たな取り組みを進めています。つまり、同市で発生するし尿と生ごみの処理にメタン発酵を使用し、発生したメタン発酵消化液を濃縮バイオ液肥(Bio-CLF)として利用する施設を2024年度から稼働させる準備を進めているからです。Bio -CLFに利用される消化液の処理量は33トン/日で、市内の水田や畑地します。写真は、濃縮バイオ液肥施設の完成イメージです。
同市におけるBio -CLFは、原料がし尿は生ごみの一般廃棄物です。一般廃棄物は、自治体が処理責任を負うため、この計画は真庭市が主導し、真庭市の予算を使って行うことが大きな大きな特徴です。また、真庭市に限らず、し尿や生ごみを原料としたメタン発酵施設の建設と管理は、さらに消化液の利用は、一般に自治体主導です。
同市には、本格施設の建設に備えて、メタン発酵施設のパイロットプラントがあり、通常のメタン発酵消化液を液体肥料として散布していますが、施設完成後には、これを濃縮バイオ液肥として散布します。そして、この濃縮バイオ液肥製造施設建設に不可欠の消化液濃縮技術は、矢部が開発した特許技術使用しています。現在、真庭市では、Bio -CLFを用いて、地元農業普及指導センターと連携を図りながら、農薬散布用のブームスプレヤーやドローンを用いて散布試験を進めています。
同市においては、何年も前から、農業者や行政関係等に対する消化液やBio-CLFの講演や、プラント建設企業に対しては専門的な技術情報の提供を行なってきております。そして、2022年に濃縮バイオ液肥プラントの建設が決定しましたので、さらに、Bio-CLFの生産技術はもちろん、Bio -CLFに関する農業技術について支援を行なっていくことになります。
Municipality-centered initiatives
Manowa City in Okayama Prefecture has a population of about 41,000, with the northern part forming the Chugoku Mountains, and has played an essential role as a model region for woody biomass utilization. Maniwa City has also been making new efforts in wet biomass production. The city is preparing to start the operation of a facility in FY2024 that will use methane fermentation to treat human waste and raw garbage and convert the digested methane fermentation liquid generated into concentrated liquid bio-fertilizer (Bio-CLF). The photo shows the concentrated bio-liquid fertilizer facility. The picture shows an image of the completed concentrated bio-fertilizer facility.
The raw materials for Bio-CLF in the city are general waste, such as human waste and kitchen garbage. Since the municipality is responsible for the disposal of general waste, a significant feature of this project is that Maniwa City will take the lead and use its budget for the project. In addition, the construction and management of methane fermentation facilities using manure and food waste as raw materials, as well as the use of digested liquid, is generally initiated by local governments, not only in Maniwa City.
In preparation for the construction of a full-scale facility, the city has a pilot plant for a methane fermentation facility. This facility produces ordinary methane fermentation-digested liquid used as liquid fertilizer. The city uses this digested liquid as a material of Bio-CLF. The digested liquid concentration technology, which is essential for constructing the full-scale Bio-CLF production facility, uses a patented technology developed by Yabe. Currently, Maniwa City is testing the use of Bio-CLF in cooperation with the local agricultural extension center, using boom sprayers and drones for pesticide spraying.
For years, in this city we have lectured on digested liquid and Bio-CLF to farmers and government officials and providing specialized technical information to plant construction companies. The city has decided to construct a Bio-CLF plant in 2022, and we will give more support for agricultural technology related to Bio-CLF and the production technology of Bio-CLF.
